Smart Efficient Hotplate Magnetic Stirrer

» General Lab Equipment » Smart Efficient Hotplate Magnetic Stirrer

  • Smart Efficient Hotplate Magnetic Stirrer

    CATEGORY AND TAGS:
    General Lab Equipment

    Model: MS7-H550-Pro

    enquiry
    • Specifications
    Key Features

    • LCD display for precise monitoring of speed and temperature
    • Built-in PID controller ensures safe heating of the medium with overheating protection
    • Max. heating plate temperature 550°C
    • Glass-ceramic work plate provides excellent chemical resistant performance and most efficient heat transfer
    • External temperature control is possible by connecting the temperature sensor(PT1000) with accuracy at ±0.2°C
    • Digital speed control, max. speed at 1500rpm
    • Outstanding brushless DC motor enables more stirring power
    • Two rotating knobs enable easy adjustment of speed and temperature
    • The “HOT” warning will flash when the work plate temperature is above 50°C even when the hotplate is turned off
    • Remote function provides PC control and data transmission

    Specifications
    Specifications
    MS7-H550-Pro
    Work plate Dimension [W x D]
    184x184mm (7 inches)
    Work plate material
    Glass-ceramic
    Motor type
    Brushless DC motor
    Motor rating input
    18W
    Motor rating output
    10W
    Power
    1050W
    Heating output
    1000W
    Voltage
    100-120/200-240V 50/60Hz
    Stirring positions
    1
    Max. stirring quantity, [H2O]
    20L
    Max. magnetic bar[length]
    80mm
    Speed range
    100-1500rpm
    resolution ±1rpm
    Speed display
    LCD
    Temperature display
    LCD
    Heating temperature range
    Room Temp.-550°C, increment 1°C
    Temperature control accuracy
    ±1 °C (<100°C) ±1%(>100°C)
    Overheating protection
    580°C
    Temperature display accuracy
    ±0.1°C
    External temperature sensor
    PT1000 (accuracy ±0.2)
    “Hot” warning
    50°C
    Data connector
    RS232
    Protection class
    IP21
    Dimension [WxDxH]
    215x360x112mm
    Weight
    5.3kg
    Permissible ambient temperature and humidity
    5-40°C, 80%RH
