Main Features
●Industrial grade color LCD display, touch screen operation
●Three kinds of linear vibration plate function.
●Ultra long soak time design 、can serve multiple purposes
●Have a variety of Washing mode、Support user programming
●Extra Wide voltage input design、Global voltage application
●Up to 4 kinds of liquid channels can be selected 、No need to replace reagent bottle
Main Parameters
Wash heads：8/12 /Wash heads, can be dismantled and Washed
Wash channels：Standard 4 channels
Residue volume ：1ul(the average per hole)
Wash Times：0-99times
Wash Strip：1-12，Support skip Washing
Delay time：0-9 seconds for delay
Injection velocity:About 100 boards/hour
Soak time：0-24 hours，Step 1 second
Wash mod：Design of advanced non positive negative pressure technology，With the center of washing, two points washing, prevent the
bottom of the cup from being scratched.
Program storage：Support user programming、200 groups of washing program storage, preview, delete, call, support for changing.
Vibrae Speed：3 grade，time: 0 – 24 hours.
Level monitor：Support the liquid level alarm function
Display：5.6 inch color LCD screen、Touch screen input，Support 7*24 hours continuous boot，And has the non working period energy
conservation management function.
Power input：AC100-240V 50-60Hz
Bottle washing： 2000mL* 3
Weight：9Kg
