TPF-100 Soil Agglomerate Analyzer

» Soil Analysis » TPF-100 Soil Agglomerate Analyzer

TPF-100 Soil Agglomerate Analyzer

CATEGORY AND TAGS:
Soil Analysis

Model: TPF-100

enquiry
  • Specifications

Introduction:

Its relationship with soil fertility is mainly reflected in: regulating the balance between soil moisture and air, coordinating nutrient consumption and accumulation, stabilizing soil temperature, improving soil workability, and promoting crop root development.

Features

  • Designed in accordance with agricultural (NY/T 1121.19-2008) and forestry (LY/T 1227-1999) standards.
  • Effectively analyzes soil particles cemented by calcium, magnesium, organic matter, andmycelium while preserving the original soil structure.
  • Control system with key-adjustable frequency, knob-set time, and high-precision digitaldisplay for accurate and fast operation.
  • Stable, safe, and reliable system with leakage protection, grounding protection, andemergency stop features.
  • Low energy consumption, low noise, and environmentally friendly.

The Technical Parameter:

Main unit size 635 mm (L) × 635 mm (W) × 895 mm (H)
Operation mode Vertical motion, 50 mm stroke, ensuring soil aggregates meet standard sieve sampling requirements
Timing range 0–60 min, adjustable
Motor speed 1350 rpm
Oscillation frequency 4–45 times/minute
Working voltage 220 V, 50 Hz
Maximum power 120 W
Sieve specifications (optional) Spec. 1 (Diameter 10 cm): 5 mm, 3 mm, 2 mm, 1 mm, 0.5 mm, 0.25 mm
Spec. 2 (Diameter 20 cm): 10 mm, 7 mm, 5 mm, 3 mm, 2 mm, 1 mm, 0.5 mm, 0.25 mm
Material Stainless steel
Oscillation frame 4 holders, supporting simultaneous testing of 4 samples
Sieve frame 4 pcs, stainless steel
