Good Quality Floor Large Capacity Refrigerated Centrifuge

CATEGORY AND TAGS:
Seed Analysis

Model: TP7-72KR

enquiry
  • Specifications
Key Features

◎Microcomputer control with touch panel LED display, driven by AC frequency conversion motor.
◎Set up freely of RPM, RFC, temperature and time. Automatically calculate RCF.
◎Up to 40 programs and parameters can be revised during operation without stopping.
◎9 steps for speed control and breaking freely.

Long life：


◎Imported Eco-Friendly CFC free (refrigerant R404a ) refrigerating compressor, heated and cooling dual system control.
◎High torque AC frequency conversion motor, free maintenance.

Safety in Operation：
◎Over speed, over heat, imbalance protections with Electronic lock.

Ultra large capacity:


◎12 X 400ml three strip bags or four strip bags, 2400ml centrifuge bottle, up to centrifuge 14400ml samples with 6x2x1000ml swing out rotor.

Applications

TP7-72KR is specially designed for customers with large capacity requirements, such as blood stations, pharmaceuticals, bioengineering and etc.



Technical Parameter



Model
TP7-72KR
Max RPM
8000rpm
Max RCF
12166×g
Max Capacity
6×2400ml
Timer
1min～23h59min
Revolutions/min
±10r/min
Temp Range
-20℃～40℃
Temp Accuracy
±1.0℃
Voltage
AC 220±22V 50Hz 50A
Power
7500W
Noise
≤ 60dB（A）
Chamber Diameter
Φ700mm
Dimensions (L x W x H)
975×860×1180 (mm)
Packaging Dimensions
1100×980×1400(mm)
Net Weight
500kg



Rotor
NO.
Capacity
Max Speed（r/min)
Max RCF(×g)
Angle Rotor
1
6×500ml
8000rpm
11680×g
2
6×1000ml
7200rpm
12166×g
Swing-out Rotor
3
6×2×1000ml
4200rpm
5000×g
4
6×2400ml
4200rpm
5600×g
