Brief description:
1. Can store 896 peaks of data .The LED show the peaks of data, and get ride of the data .
2. Can output data; analyze the data by connected with computer.
3. With digital peak value holding function, hold the peak value for 2 seconds and the peak value will be automatically cancelled.
4. Green environmental-protective: If you do not operate the machine after 10 seconds, the machine will be shut down automatically.
Technical parameters:
| Model |
GY-4 |
| Measurement Range |
0.2 – 15 Kg/cm2 (×105 Pa ) |
0.4 – 30 Kg/cm2 (×105 Pa ) |
| Division value |
0.01 Kg/cm2 |
0.01 Kg/cm2 |
| Pressure head diameter |
1# ¢11.1mm |
2# ¢7.9mm |
| Precision |
±1% |
| Indication error |
±0.5% |
| Unit |
Kg/cm2(×105 Pa) |
| Data interface |
RS232 nine-hole socket |
| Display mode |
Digital |
| Sensor structure |
Tye sensor with high precision (inner sensor) |
| Insertion depth of pressure head |
10mm |
| Ambient temperature |
5°c~35°c |
| Ransport temperature |
-10°c~60°c |
| Relative humidity |
15%~80%RH |
| Net weight |
450g |
| Outline dimension |
230*66*36mm |
