    Pesticide Residue Tester-Pesticide Residue Analysis and Testing

    Model:NY-8DA

    enquiry
    • Specifications

    Name: Pesticide Residue Tester

    1. Principle of Instrument
    Pesticide Residue Tester is based on cholinesterase catalyzing acetylcholine, its hydrolysate impacts DTNB to form yellow AZO. Organophosphate pesticides has effect on enzyme. Through changes of absorption value show the degree of inhibition and further reflect the pesticide residue in samples. The instrument consist of LED, thermostatic color pool, integrated photoelectric sensors, ARM9 microprocessor and miniature printer and can print directly and transit result of testing.

    2. Characteristics
    Testing pesticide residue in onion, garlic, ginger, fragrant-flowered garlic, carrot tomato, vegetables etc.
    Color reaction under room temperature condition, fast testing speed
    Plastic shell, streamline appearance, 6 inch color LCD displayer, easy to operate
    High sensitivity to methamidophos, dichlorvos and so on
    Adopt ARM9 inserting controlling system, with the function of saving, collecting, processing, analyzing

    3. Technical parameter
    The test items, detection limit, detection range:
    test items
    detection limit
    detection range
    pesticide residue
    0.1-20mg/kg
    0-100%
    ( inhibition ratio)
    Transmittance accuracy: ≤±1.5%;
    Transmittance repeatability: ≤ 0.5%
    Linear error: ≤5%
    Mode of display: LCD
    Interface: network
    Working environment: temperature: 0~40°C, humidity: 35~85%
    Power adaptor: 220V to 5V/5A
    Size: 38CM * 30CM* 17CM

    The test items, detection limit, detection range:
    test items
    detection limit
    detection range
    pesticide residue
    0.1-20mg/kg
    0-100%
    ( inhibition ratio)
    Transmittance accuracy: ≤±1.5%;
    Transmittance repeatability: ≤ 0.5%
    Linear error: ≤5%
    Mode of display: LCD
    Interface: network
    Working environment: temperature: 0~40°C, humidity: 35~85%
    Power adaptor: 220V to 5V/5A
    Size: 38CM * 30CM* 17CM
