Electronic Volume-weight Apparatus

» Seed Analysis » Electronic Volume-weight Apparatus

Electronic Volume-weight Apparatus

CATEGORY AND TAGS:
Seed Analysis

Model:  GHCS-1000

enquiry
  • Specifications

Introduction:

Grain Volume-Weight Meter is a specialized instrument to measure the grade of food. It can not only measure millet, wheat, sorghum and other small particles of grain, but also corn, soybeans and other large particles of grain.

This series of volume-weight Meter adopt testing results digital display and automatically printing measurement, electronic weighing technology, with the characteristics of easy operation,high accuracy and high testing speed. It has been an essential instrument for departments of quality supervision, food processing, research, agriculture, breeding, schools, etc.

Technical specification

1.Maximum weighing load: 1000g ±2g

2.Weighing resolution: 1g

3.Density barrel volume: 1000±1.5ml

4.Power: AC 220V±10V 50 Hz

5.Working temperature: 5℃-40℃ relative humidity: <90%RH

6.Blanking mouth diameter: particles 30mm large particles 50mm

7.Measuring mode: combined measurement

8.Overall dimension: 530*230*405mm

9.Weight: 12g
